8.4. Storage and Shipment
8.4.1. Storage Environment
The amplifier may be kept packed in a dry, ventilated and unheated location (with no chemically active
substances such as acids or alkalis) within the following environment ranges:
• Temperature range: -40 to +70 degrees Celsius (-40
o
F to 158
o
F);
• Humidity: up to 75% @ +35 degrees Celsius (95
o
F).
8.4.2. Shipping Size and Weight
• WxDxH: Approx. 500x470x380 mm, 11.6 kg (19.7x18.5x15.0 inches, 25.6 lbs.);
Please, contact ACOM (see 1.5 Owner Assistance) for shipment details.
Figure 8-1 | Packaging cardboard box
Figure 8-1 | Packaging cardboard box
8.4.3. Transportation
All types of transportation may be used, including storage in an aircraft baggage compartment at up to 12000
meters (40000 ft) above sea level.
