6.2 LED Colours
The colour of the top LED might be different depending on the operational mode. The
following operational modes are distinguished:
• Normal (single band) mode
In the normal single band mode, the top LED will be Yellow.
• Dual Band Mode
In Dual Band mode, the LED colour shows the operational frequency:
Green .................. : Europe/International
Red ..................... : North America / USA
• Site Survey mode (only applicable for the 4080 IP-DECT in the Site Survey Kit.)
Green .................. : Europe/International
Red ..................... : North America / USA
Blue .................... : Latam
Magenta ............... : China and Thailand
