1 Press the button with the
arrow until the symbol for
gas heating ashes. The text
“ON” is displayed next to the
temperature on the display.
2 Switch off the gas heating by
pressing the -/Off button. The
text “OFF” is displayed next to
the temperature on the display.
3 Press the button to the left
until the control panel reverts
to standby. The symbol for gas
heating is no longer displayed.
Do as follows to switch off the gas heating.
7. Heating with 230 V electric
1 Press the button with the arrow
until the symbol for electrical
heating ashes.
2 Select power (1kW, 2kW or 3kW)
by using buttons +/On or -/Off.
The diagram shows that the
3kW has been selected (not all
caravans can select 3kW, some
can only select 1-2kW).
3 Press the arrow to the left until
the control panel reverts to
standby. The symbol for electrical
heating is displayed constantly.
The more kW power used the quicker the heat up time. 3kW is not available on all boilers.
1 Press the button with the arrow
until the symbol for electrical
heating ashes.
2 Switch off the electrical heating
by pressing the -/Off button until
all power steps have gone out.
3 Press the arrow to the left until
the control panel reverts to
standby. The electrical heating
symbol has now gone out.
Do as follows to switch off heating with electricity.
GB
8. Circulation pump
This symbol means that the circulation pump is
operating (12V Pump or 230V Pump). When tted to the
boiler will select the 230 V Pump automatically when
230 V voltage is supplied to the boiler.
9. 230V connection
This symbol is lit up when 230V voltage is connected to
the caravan.
ashes
ashes ashes
ashes
ashes
7
