GL4800 User Guide 37
The Snapshot Display
Normal Mode
Shows selected snapshot number 0 to 127 or ALL
Indicates which snapshot which will overwrite the console
mutes when you press RECALL, or be overwritten when you
press STORE. The ACTIVE dot tells you how the displayed
number relates to the current console mute settings:
ACTIVE on :
Displayed snapshot is the last snapshot recalled.
Console mutes are the same as the displayed snapshot
(except for channels made 'safe').
ACTIVE off :
Displayed snapshot is the last snapshot recalled.
Console mutes have changed since the snapshot was recalled.
ACTIVE flashing :
Displayed snapshot is not the same as the last snapshot
recalled. This is always the case in 'auto-increment' mode
where the display automatically steps up ready for recall.
Clear or Set all Mutes
Flashes CLr or SEt to warn that all console mutes will be
turned on or off when this function is selected.
Console Mode
The MODE dot turns on.
2 digit code indicates the selected console mode. Digit 3
shows if the mode is selected ( = ) or not ( ).
MIDI Channel Number
The MIDI CHANNEL dot turns on.
The display indicates the console MIDI channel number
selected. This can be channel 1 to 16 or OFF
Software Version Number
Refer to the section on TECHNICAL SUPPORT.
Error Codes
Displays the error number and code referenced in the section
on TECHNICAL SUPPORT.
EDIT
SAFES
RECALL
PREVIEW
STORE
IN-PLACE
SOLO
SNAPSHOT
<
>
MIDI
CHANNEL
ACTIVE
PATCH
MODE
SHIFT
DISABLE
AUTO
INCREMENT
