ALLEN&HEATH Xone:92 parts identification inc storm grey Issue 3 Page 7 of 9
INTERIOR PARTS:
Stereo fader 002-684
Linear fader 003-144
Rotary fader 003-145 (92R)
Mic/Stereo Return 003-136
Stereo 003-137
