Compact I/O Expansion Power Supplies
Specifications
Technical Specifications
Attribute 1769-PA2 1769-PB2 1769-PA4 1769-PB4
Input voltage range 85…265V AC 19.2…31.2V DC 85…132V AC or
170…265V AC, switch
selectable
19.2…32V DC
Input frequency range 47…63 Hz N/A 47…63 Hz N/A
Power supply distance
rating
(1)
(1) You can use a maximum of two banks of I/O modules. This condition occurs when configuring your system with a MicroLogix 1500 controller, one
expansion cable, one expansion power supply, and a total of eight I/O modules. The expansion power supply cannot be directly connected to the
MicroLogix 1500 controller.
8
8 I/O modules can be connected on either side of the power supply for a maximum of 16 modules
Operating altitude 2000 m (6562 ft)
Isolation voltage 265V (continuous),
Reinforced Insulation Type
Routine tested at
2596V DC for 1s, AC Power
Input to System and AC
Power Input to 24V DC
User Power
75V (continuous),
Reinforced Insulation Type
Routine tested at
1697V DC for 1s, DC Power
Input to System
265V (continuous),
Reinforced Insulation Type
(IEC Class 1 grounding
required)
Routine tested at
2596V DC for 1s, AC Power
Input to System
75V (continuous),
Reinforced Insulation Type
(IEC Class 1 grounding
required)
Routine tested at
1697V DC for 1s, DC Power
Input to System
Power consumption 100VA @ 120V AC
130VA @ 240V AC
50VA @ 24V DC 200VA @ 120V AC
240VA @ 240V AC
100VA @ 24V DC
Power dissipation 8 W @ 60 °C (140 °F) 7.5 W @ 60 °C (140 °F) 18 W @ 60 °C (140 °F) 14.5 W @ 60 °C (140 °F)
Current capacity @ 5V DC 2.0 A 2.0 A 4.0 A 4.0 A
Current capacity @ 24V DC 0.8 A 0.8 A 2.0 A 2.0 A
Inrush current, max 25 A @ 132V AC 30 A @ 31.2V DC 25 A @ 132V AC 30 A @ 31.2V DC
Fuse type Littelfuse 02153.15MXP Littelfuse 021706.3MXP Wickmann
19195-3.15A
Littelfuse 02183.15MXP
Wickmann 19193-6.3A
Littelfuse 021706.3MXP
Dimensions (HxWxD),
approx
118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)
height including mounting tabs is 138 mm (5.43 in.)
Weight, approx 485 g (1.07 lb) 630 g (1.39 lb)
Wiring category
(2)
(2) Use this Conductor Category information for to plan conductor routing. See the Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
.
1 on power ports 2 on power ports 1 on power ports 2 on power ports
Wire size 2.5 mm
2
(14 AWG) solid copper wire rated at 90 °C (194 °F), or greater, 1.2 mm (3/64 in.) insulation max
North American temp
code
T3C
IEC temp code N/A T4 N/A T4
Enclosure type rating None (open-style)
