32 Rockwell Automation Publication 1769-IN028C-EN-P - August 2016
Compact I/O Expansion Power Supplies
Environmental Specifications
Attribute 1769-PA2 1769-PB2 1769-PA4 1769-PB4
Temperature, operating
IEC 60068-2-1 (Test Ad,
Operating Cold
IEC 60068-2-2 (Test Bd,
Operating Dry Heat)
IEC 60068-2-14 (Test Nb,
Operating Thermal Shock)
0…60 °C (32…140 °F)
Temperat ure,
non-operating
IEC 60068-2-1 (Test Ab,
Unpackaged Non-
operating Cold)
IEC 60068-2-2 (Test Bb,
Unpackaged Non-
operating Dry Heat)
IEC 60068-2-14 (Test Na,
Unpackaged Thermal
Shock)
-40…+85 °C (-40…+185 °F)
Relative humidity
IEC 60068-2-30 (Test Db,
Unpackaged Damp Heat)
5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc,
Operating)
5 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
DIN rail mount: 20 g
Panel mount: 30 g
Shock, nonoperating
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
DIN rail mount: 30 g
Panel mount: 40 g
Emissions
CISPR 11
Group 1, Class A
ESD immunity
IEC61000-4-2
6 kV contact
8 kV air discharges
Radiated RF immunity
IEC61000-4-3
10V/m with 1 kHz sine-
wave 80% AM from
80…2000 MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 900
MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 1890
MHz
3V/m with 1 kHz sine-
wave 80% AM from
2000…2700 MHz
10V/m with 1 kHz sine-
wave 80% AM from
80…2000 MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 900
MHz
10V/m with 1 kHz sine-
wave 80% AM from
80…2000 MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 900
MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 1890
MHz
3V/m with 1 kHz sine-
wave 80% AM from
2000…2700 MHz
10V/m with 1 kHz sine-
wave 80%AM from
80…2000 MHz
10V/m with 200 Hz 50%
Pulse 100% AM at 900
MHz
EFT/B immunity
IEC 61000-4-4
±2 kV at 5 kHz on AC
power ports
±2 kV at 5 kHz on 24V DC
PWR OUT ports
±2 kV at 5 kHz on DC
power ports
±2 kV at 5 kHz on AC
power ports
±2 kV at 5 kHz on DC
power ports
