40 Rockwell Automation Publication 2080-UM004C-EN-E - March 2015
Appendix 5 DeviceNet Plug-in – 2080-DNET20
Network Configuration
In order to configure the DeviceNet plug-in and scan the network, you need to
import user-defined function blocks (UDFBs) in your Micro800 project in
Connected Components Workbench. Autoscan is used to add nodes into the
scan list.
Network Wiring
The DeviceNet specifications provide for maximum network distances for the
main trunk line and drop lines, depending upon the baud rate used on the
network.
Module Status Indicator
LED state Module status Description
OFF No power There is no power present.
Flashing Green Operational Unit is starting up.
Green Unit operational Device is operating normally.
Flashing Red Minor fault. A recoverable fault is present or the module is
undergoing firmware update.
Red Unrecoverable fault. A non-recoverable fault is detected.
Network Status Indicator
LED state Module Status Description
OFF No power or offline There is no network power or device is not operating.
Flashing Green Idle No valid network connection has been made.
Green Online The plug-in module is operating normally and receiving
messages.
Flashing Red Connection time out One or more network connections has timed out.
Red Critical link failure The plug-in module has detected an error that makes it
incapable of communicating on the link (Bus Off or
duplicate MAC_ID).
It is recommended that when Autoscan is running for the nodes in
range, or for the connection to be established, the nodes should be idle
without any pre-occupied connections requests.
Network Specifications
Baud Rate Trunk Line Length Drop Length
Maximum Distance Maximum Cumulative
Meters Feet Meters Feet Meters Feet
125k baud 420 1377 6 20 156 512
250k baud 200 656.17 6 20 78 256
500k baud 75 246 6 20 39 128
