Drive Setup – Reset Defaults
Use the steps below to reset the drive to its default settings.
1. Press the ‘Folders’ button on the HIM keypad.
The button is located on the bottom row of the HIM Keypad (shown circled in the left image below). Pressing the ‘Folders’
button changes the HIM screen display to the Folders screen (see right image below).
PowerFlex 755
20G . . . B4P2
240V 4.2A
00
PORTS
05
Universal Fdbk
00 PowerFlex 755
01 20-HIM-x
6
06 Dual Encoder
2. Use the Enter key located in the center of the HIM keypad to select 00 PowerFlex 755.
3. Now, use the left or right arrow keys to navigate to the Memory heading, then select Set
Defaults.
4. Select This port only, then select the All option using the Enter key.
At this time the drive may display Fault 58, which is expected.
5. Clear the fault using the Red stop key (if necessary), then Confirm the reset.
6. Press ESC twice to return to the main display.
