154 Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017
Appendix D EtherNet/IP Objects
DPI Fault Object
Products such as PowerFlex drives use this object for faults. Option
modules use this object for events.
The number of instances depends on the maximum number of faults or
events that are supported in the queue. The maximum number of faults/
events can be read in Instance 0, Attribute 2.
Table 58 - DPI Fault Object: Class Code
Hexadecimal Decimal
0x97 151
Table 59 - DPI Fault Object: Services
Service Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Table 60 - DPI Fault Object: Instances
Instances Device Example Description
(Hex.) (Dec.)
0x0000…0x0FFF 0…4095 Host Drive 0 Class Attributes (Drive)
0x1000…0x1FFF 4096…8191 Port 1 1 Most Recent Drive Fault
0x2000…0x2FFF 8192…12287 Port 2 2 Second Most Recent Drive Fault
0x3000…0x3FFF 12288…16383 Port 3
…
…
0x4000…0x4FFF 16384…20479 Port 4 4096 Port 1 Class Attributes
0x5000…0x5FFF 20480…24575 Port 5 4097 Port 1 Most Recent Event
0x6000…0x6FFF 24576…28671 Port 6
…
…
0x7000…0x7FFF 28672…32767 Port 7
0x8000…0x8FFF 32768…36864 Port 8
0x9000…0x9FFF 36864…40959 Port 9
0xA000…0xAFFF 40960…45055 Port 10
0xB000…0xBFFF 45056…49151 Port 11
0xC000…0xCFFF 49152…53247 Port 12
0xD000…0xDFFF 53248…57343 Port 13
0xE000…0xEFFF 57344…61439 Port 14
