Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017 21
Getting Started Chapter 1
User-supplied Equipment
To configure the built-in EtherNet/IP interface, you must supply the
following:
• A small flat-blade screwdriver for setting the network address switches.
• An Ethernet cable (for details, see the EtherNet/IP Media Planning and
Installation Manual, ODVA publication 148, available on the ODVA
website at http://odva.org/Home/ODVATECHNOLOGIES/
EtherNetIP/EtherNetIPLibrary/tabid/76/Default.aspx). Note: A user
name and password are required to access the ODVA publications.
• An Ethernet switch (for details, see the Ethernet Design Considerations
Reference Manual, publication ENET-RM002
).
Configuration Tool Options
Any of the following configuration tools can be used:
• PowerFlex 20-HIM-A6 or 20-HIM-C6S HIM
• Connected Components Workbench (CCW) software release 10 or
later
• Connected Components Workbench is the recommended standalone
software tool for use with PowerFlex drives. You can obtain a free copy
by internet download at the Product Compatibility and Download
Center, which is located at http://
compatibility.rockwellautomation.com/Pages/home.aspx.
• Controller configuration software, such as RSLogix 5000 software,
version 20, or Studio 5000 Logix Designer® application, version 21 and
later.
• Automatic Device Configuration (ADC), an RSLogix 5000 and
Studio5000 software feature that supports the automatic download of
configuration data. The download occurs as the Logix controller
establishes an EtherNet/IP network connection to a PowerFlex 755TR,
755TL, or 755TM drive and its associated peripherals. The AOP must
be installed for ADC to be functional with Studio 5000 or RSLogix in
versions newer than version 30. After version 30, the AOP comes
preinstalled in Studio 5000.
• A computer connection to the EtherNet/IP network.
