Modero X® Series Touch Panels
9
MXD/T-1000 10.1" Modero® X Series Touch Panels
Memory
The MXD-1000 comes with 512 MB of SDRAM and 4 GB of Flash memory, neither of which can be
upgraded. A maximum of 2.4 GB is available to the user for projects.
Basic Operation
The MXD-1000 is operated using its integral touchscreen, as well as the Sleep button on the top of the device
(FIG. 4). If the device has gone into its Sleep Mode, a touch of the touchscreen or of the Sleep button will
reactivate it.
Powering on the MXD-1000
The MXD-1000 may be powered on by touching and holding the Sleep button on the top of the device.
Microphone
The MXD-1000 contains a built-in microphone above the touch screen for video and audio conferencing
capabilities. This microphone is concealed by the casing.
Audio/Video Capabilities
The MXD-1000 has the capability of displaying multiple JPEG and PNG files at one time. The device also
supports streaming motion JPEG video (of the sort used by many IP and Web cameras), as well as MP3 and
WAV audio files.
MXD-1000-NC
The MXD-1000-P-NC (FG5968-25) and MXD-1000-L-NC (FG5968-26) No Comm touch panels do not have
camera, microphone, or NFC capability. These otherwise have all of the functionality of the MXD-1000
panels.
FIG. 6 Rear of the MXD-1000 (Portrait)
RJ45
Port
USB Port
Micro-USB
Port
Top
