NFPA Standard-Specific Requirements
36 Autopulse-442R 50098:F 05/24/2001
%1)3$
6LJQDOOLQJ
6\VWHPV
²$&
&HQWUDO
6WDWLRQ
6HUYLFHDQG5HPRWH6WDWLRQ3URWHFWLYH6HUYLFH
3URWHFWHG3UHPLVHV8QLW
NOTI-FIRE 911AC DACT* for connection to a Central Station Receiver or Protected Premises
Receiving Unit. This unit must be installed as illustrated below. All connections between the
FACP and 911AC must be in conduit, less than 20 ft. (609.6 cm) in length in the same room.
* This application using the NOTI-FIRE 911A is not FM approved.
Note: The Autopulse-442R is not suitable for transmission of a supervisory signal to the DACT.
1
2
4
6
7
8
9
10
11
12
3
5
1
2
5
6
7
8
9
10
12
13
14
15
16
17
3
4
11
12VAC, 20VA, 6 0Hz or +24VDC
12VAC, 20VA, 6 0Hz or -24VDC
(Refer to manual)
BATTERY -
BATTERY +
INI TIATING A1 -
INI TIATING A2 -
INI TIATING B1 +
INI TIATING B2 +
SUPERVISORY HI
SUPERVISORY LO
TROUBLE RELAY NC
TROUBLE RELAY COM
TROUBLE RELAY NO
ALARM RELAY NC
ALARM RELAY COM
ALARM RELAY NO
Digital Alarm Communicator Transmitter Listed for Central Station or Remote Station Service.
Slide Cover Back to Access Programming Jack and Relays
Primary RJ31X
Tel co Ja c k
Alternate RJ31X
Tel co Ja c k
- 12 VDC Sealed
Rechargeable
+ Battery
PS1270
12Volt
7AH Battery
+
-
NOTE on STD DACT:
Place jumper over pins 2 and 3,
marked DACT, when employing a
DACT. This directs the control panel
to transmit all trouble conditions
except AC LOSS.
STDDACT
To Central Station
Alarm
JP-1
Motherboard 911AC
Alarm
normally open contacts
TB3-1 6 and 7
TB3-3 8 and 9
Trouble
normally open contacts
TB3-4 10
TB3-6 11
53$&FGU
To AC
Power
