use and maintenance Gulliver 50
29
Checking and topping up
Proceed as follows:
◆
Position the vehicle on the stand.
◆
Unscrew the screw (1) and remove the
front hood (2).
◆
Make sure that the level of the fluid con-
tained in the expansion tank (3) is includ-
ed between the "MIN" and "MAX" notch-
es (see figure).
◆
If not, unscrew and remove the filling
plug (4).
◆
Top up until the fluid reaches approx. the
"MAX" notch. Do not exceed this level,
otherwise the fluid will flow out of the
tank when the engine is running.
◆
Put back the filling plug (4).
◆
Put back the front hood (2) and tighten
the screw (1).
In case of excessive consump-
tion of coolant and in case the
expansion tank remains empty,
make sure that there are no leaks in the
circuit.
Have it repaired by an APRILIA Official
Dealer.
a
1
2
43
