Chapter 2 Installation
is is a deep micro-ATX form factor (9.6” x 10.5”) motherboard. Before installing the
motherboard, study the conguration of the chassis to ensure that the motherboard ts
into it.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Attention! Before installing this motherboard, be sure to unscrew and remove the stando
at the marked location, under the motherboard, from the chassis, in order to avoid electri-
cal short circuit and motherboard damages.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions
Take note of the following precautions before installing motherboard components or
change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the motherboard’s components due to static electricity, NEVER
place the motherboard directly on the carpet or the like. Also remember to use a
grounded wrist strap or touch a safety grounded object before handling the compo-
nents.
3. Hold components by the edges and do not touch the ICs.
4. Whenever uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the motherboard to the chassis,
please do not over-tighten the screws! Doing so may damage the motherboard.
Before installing or removing any component, ensure that the power is switched o or the
power cord is detached from the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries and motherboard damages.
