ROG Blitz Formula 4-31
4.6.6 Hardware Monitor
CPU Temperature; MB Temperature; NB Temperature;
SB Temperature; OPT Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU,
motherboard, northbridge, southbridge, and the assigned device temperatures.
Select [Ignored] if you do not wish to display the detected temperatures.
North Bridge Overheat Protection [Auto]
Allows you to enable/disable the northbridge overheat auto-protection function or
set the temperature over which the system shuts down.
Conguration options: [Auto] [70C] [80C] [Disabled]
South Bridge Sensor Select [SB Overheat Protection]
Allows you to switch the target the temperature sensor aims at between the
southbridge and any device with a thermal sensor cable connected to the
OPT_TEMP2 connector.
Conguration options: [SB Overheat Protection] [OPT_TEMP2]
Remove the thermal sensor cable from the assigned device when you set this
item to [SB Overheat Protection].
The next item varies depending on whether you set the South Bridge Sensor
Select item to [SB Overheat Protection] or [OPT_TEMP2].
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Hardware Monitor
CPU Temperature [38.5ºC/102ºF]
MB Temperature [36ºC/96.5ºF]
NB Temperature [35ºC/95ºF]
SB Temperature [43ºC/109ºF]
OPT Temperature [N/A]
North Bridge Overheat Protecti [Auto]
South Bridge Sensor Select [SB Overheat Protec]
south Bridge Overheat Protecti [Auto]
OPT_TEMP1 Overheat Protection [Disabled]
CPU Fan and Chassis Fan
OPT Fan and Power Fan
VCORE Voltage [ 1.272 V]
FSB Termination Voltage [ 1.248 V]
North Bridge Voltage [ 1.280 V]
DRAM Voltage [ 1.904 V]
CPU Temperature
BIOS SETUP UTILITY
Power
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
Scroll down to see more items.
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
DRAM Reference Voltage [ 0.944 V]
South Bridge Voltage [ 1.088 V]
PLL Voltage [ 1.536 V]
3.3V Voltage [ 2.992 V]
5V Voltage [ 4.776 V]
12V Voltage [11.872 V]
To Next Page
