Asus CS-B User Manual

vi
CS-B specications summary
(continued on the next page)
CPU LGA1150 socket for Intel
®
4th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
* Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Q87 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-
buffered memory
Dual-channel memory architecture
* Intel
®
4th generation supports DDR3 1600 and higher memory frequency.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated Graphics Processor
Multi-VGA output support: DisplayPort, DVI-D, and DVI-I ports
- Supports DisplayPort with max. resolution of 4096 x 2160@24Hz /
3840 x 2160 @60Hz
- Supports DVI-D with max.resolution of 1920 x 1200 @60Hz
- Supports DVI-I with max. resolution of 1920 x 1200 @60Hz
Maximum shared memory of 1024 MB
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot
1 x PCI Express 2.0 x16 slot (x4 mode)
1 x PCI Express 2.0 x1 slot
1 x PCI slot
1 x mini PCIe (Full length, supports full/half mini card)*
* mini PCIe shares the same slot with mSATA. When a mini PCIe card is installed,
mSATA will not be usable.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS CS-B motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus CS-B Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-4xxx, i5-4xxx, i7-4xxx
CPU fan connector	Yes
USB 2.0 connectors	2
Number of SATA connectors	-
Number of SATA III connectors	5
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887-VD
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Q87
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
Maximum resolution	4096 x 2160 pixels
Number of displays supported	3
Cables included	SATA
LAN controller	Realtek RTL8111G
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	2.0a
BIOS memory size	16 Mbit

Weight and Dimensions

Width	244 mm
