11
1.6.1 Wired connection
NOTE: You can use either a straight-through cable or a crossover cable
for wired connection.
To set up your xDSL modem router via wired connection:
1. Insert your xDSL modem router’s power adapter to the DC-IN
port and plug it to a power outlet.
2. Connect one end of the RJ-11 cable to the DSL port of your
xDSL modem router, and connect the other end to the DSL
port of your splitter.
3. Using a network cable, connect your computer to your xDSL
modem router’s LAN port.
IMPORTANT! After turning on your xDSL modem router, wait for about
two to three minutes for it to boot up.
Wall telephone outlet
Computer
Wall Power Outlet
Power
LAN
Splitter
Phone
DSL
To Next Page
