Asus F1A55-M LX PLUS R2.0 User Manual

DDR3-1066 MHz capability
SS: Single-sided / DS: Double-sided
DIMM support:
• 1 DIMM: Supports one module inserted into either slot as single-channel memory
conguration.
• 2 DIMMs: Supports one pair of modules inserted into both the slots as one pair of dual-
channel memory conguration.
Visit the ASUS website at www.asus.com for the latest QVL.
Vendors Part No. Size SS/DS Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
Crucial CT12864BA1067.8FF 1GB SS Micron 9GF22D9KPT 7 - • •
Crucial CT12872BA1067.9FF 1GB SS Micron 9HF22D9KPT(ECC) 7 - • •
Crucial CT25664BA1067.16FF 2GB DS Micron 9HF22D9KPT 7 - • •
ELPIDA EBJ10UE8EDF0-AE-F 1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V(low voltage) • •
ELPIDA EBJ21UE8EDF0-AE-F 2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V(low voltage) • •
KINGSTON KVR1066D3N7/1G(low proile) 1GB SS ELPIDA J1108BFSE-DJ-F 7 1.5V • •
KINGSTON KVR1066D3N7/2G 2GB DS ELPIDA J1108BDSE-DJ-F 7 1.5V • •
KINGSTON KVR1066D3N7/4G 4GB DS Hynix H5TQ2G83AFR 7 1.5V • •
Micron MT8JTF12864AZ-1G1F1 1GB SS Micron 9GF22D9KPT 7 - • •
Micron MT16JTF25664AZ-1G1F1 2GB DS Micron 9HF22D9KPT 7 - • •
Chapter 1: Product introduction1-16

Asus F1A55-M LX PLUS R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2250 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	No
Number of SATA II connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Controller interface type	AMD A55 FCH
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Certification	RoHS\\r ErP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
Graphics card	Radeon HD 6000
DirectX version	11
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu
PCI Express slots version	2.0
PCI Express configurations	1x1, 1x4, 1x16
Trial software	Antivirus
Cables included	SATA
Bundled software	ASUS utilities\\r ASUS Update
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	3.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
