Asus F1A55-M LX PLUS R2.0 User Manual

2-14 ASUS F1A55-M LX R2.0 Series
2.4.5 DRAM Timing Control
The sub-items in this menu allow you to set the DRAM timing control features. Use the <+>
and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard
and press <Enter>.
Changing the values in this menu may cause the system to become unstable! If this
happens, revert to the default settings.
2.4.6 Hybrid DIGI+ VRM
Load-Line Calibration [Auto]
Load-line is dened by AMD VRM specications, and affects CPU voltage. The CPU
working voltage will decrease proportionally to CPU loading. Higher load-line calibration
would get higher voltage and better overclocking performance, but increases the CPU and
VRM thermal conditions. This item allows you to adjust the voltage range from the following
percentages to boost the system performance: 0% (Regular), 25% (Medium), 50% (High),
75% (Ultra High) and 100% (Extreme). Conguration options: [Auto] [Regular] [Medium]
[High] [Ultra High] [Extreme]
The actual performance boost may vary depending on your CPU specication.
CPU/NB Load-Line Calibration [Auto]
Allows you to select the CPU/NB Load-line mode. Conguration options: [Auto] [Regular]
[High] [Extreme]
VRM Fixed Frequency [xxx]
Allows you to set a xed VRM frequency. Use the <+> and <-> keys to adjust the value. The
values range from 250k Hz to 400k Hz with a 50k Hz interval.
CPU Power Phase Control [Standard]
Allows you to control the power phase based on the CPU’s demands. Conguration options:
[Standard] [Optimized] [Extreme] [Manual Adjustment]
Manual Adjustment [Fast]
Select [Ultra Fast] for a faster response. The reaction time will be longer when [Regular] is
selected. Conguration options: [Ultra Fast] [Fast] [Medium] [Regular]
Do not remove the thermal module while changing the Hybrid DIGI+ VRM related
parameters. The thermal conditions should be monitored.
2.4.7 CPU Voltage [Offset Mode]
[Offset Mode] To offset the voltage by a positive or negative value.
CPU Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.

Asus F1A55-M LX PLUS R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2250 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	No
Number of SATA II connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Controller interface type	AMD A55 FCH
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Certification	RoHS\\r ErP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
Graphics card	Radeon HD 6000
DirectX version	11
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu
PCI Express slots version	2.0
PCI Express configurations	1x1, 1x4, 1x16
Trial software	Antivirus
Cables included	SATA
Bundled software	ASUS utilities\\r ASUS Update
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	3.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
