F1:Help : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit : Select Menu Enter: Select SubMenu F10: Save and Exit
Phoenix-Award BIOS CMOS Setup Utility
Main Advanced Power Boot Tools Exit
2.3 Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving
you an overview of the basic system information.
Refer to section “2.2.1 BIOS menu screen” for information on the menu screen
items and how to navigate through them.
2.3.1 System Time [xx:xx:xx]
Allows you to set the system time.
2.3.2 System Date [Day xx/xx/xxxx]
Allows you to set the system date.
2.3.3 Legacy Diskette A [1.44M, 3.5 in.]
[720K , 3.5 in.] [1.44M, 3.5 in.]
System Time 15 : 30 : 36
System Date Mon, Mar 2 2006
Legacy Diskette A: [1.44M, 3.5 in.]
Primary IDE Master [ST321122A]
Primary IDE Slave [ASUS CDS520/A]
SATA1 [None]
SATA2 [None]
SATA3 [None]
SATA4 [None]
HDD SMART Monitoring [Disabled]
Installed Memory 512MB
Usable Memory 512MB
2.3.4 IDE Conguration
devices installed in the system. Select an item then press <Enter> if you wish to
IDE Conguration
Onboard IDE Controller [Enabled]
Serial-ATA Devices [Enabled]
SATA Mode select [SATA Mode]
Onboard IDE Controller [Enabled]
Allows you to enable or disable the onboard IDE controller.
Serial-ATA Devices [Enabled]
Allows you to disable or set the Serial-ATA devices.
SATA Mode select [SATA Mode]
Allows you to select the SATA Mode.
The following items appears only when the SATA Mode select item is set to
[RAID Mode].
SATA Primary Master/Slave Channel [Disabled]
Allows you to disable or enable the Serial-ATA Primary Master/Slave Channel.
SATA Secondary Master/Slave Channel [Disabled]
Allows you to disable or enable the Serial-ATA Secondary Master/Slave Channel.
