Power Down Control [Auto]
Allows DIMMs to enter power down mode by deasserting the clock enable signal
when DIMMs are not in use.
DRAM ECC Enable [Enabled]
Enables or disables the DRAM ECC that allows the hardware to report and
correct memory errors automatically.
4-Bit ECC Mode (or ECC Chip Kill) [Disabled]
Enables or disables the ECC chip kill feature.
DRAM SCRUB REDIRECT [Disabled]
Enables or disables the DRAM SCRUB REDIRECT feature that allows the
system to correct the DRAM ECC errors immediately when they occur.
DRAM BG SCRUB [Disabled]
[40ns] [80ns] [160ns] [320ns] [640ns] [1.28us] [2.56us] [5.12us] [10.2us]
[20.5us] [41.0us] [81.9us] [163.8us] [327.7us] [655.4us]
L2 Cache BG Scrub [Disabled]
Disables or sets the L2 Cache BG Scrub. This item allows the cache RAM
[160na] [320ns] [640ns] [1.28us] [2.56us] [5.12us] [10.2us] [20.5us] [41.0us]
[81.9us] [163.8us] [327.7us] [655.4us]
Data Cache BG Scrub [Disabled]
Disables or sets the Data Cache BG Scrub. This item allows the data cache
[40ns] [80ns] [160na] [320ns] [640ns] [1.28us] [2.56us] [5.12us] [10.2us]
[20.5us] [41.0us] [81.9us] [163.8us] [327.7us] [655.4us]
ECC Conguration
DRAM ECC Enable [Enabled]
4-Bit ECC Mode [Disabled]
DRAM SCRUB REDIRECT [Disabled]
DRAM BG Scrub [Disabled]
L2 Cache BG Scrub [Disabled]
Data Cache BG Scrub [Disabled]
ECC Conguration
DRAM ECC allows
hardware to report
and correct memory
errors automatically
maintaining system
integrity.
To Next Page
