1-4 Chapter 1: Product introduction
1.3.2 Innovative ASUS features
Green ASUS
This motherboard and its packaging comply with the European Union’s Restriction
on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision
of creating environment-friendly and recyclable products/packaging to safeguard
consumers’ health while minimizing the impact on the environment.
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a
disk containing the BIOS le. This utility saves users the cost and hassle of buying a
replacement BIOS chip.
ASUS EZ Flash 2
Simply update BIOS from a USB ash disk before entering the OS
EZ Flash 2 is a user-friendly BIOS update utility. Simply launch this tool and update
BIOS from a USB ash disk before entering the OS. You can update your BIOS only
in a few clicks without preparing an additional oppy diskette or using an OS-based
ash utility.
ASUS MyLogo2™
Personalize your system with customizable boot logo
You can convert your favorite photo into a 256-color boot logo for a more colorful
and vivid image on your screen.
AI NET2
Diagnose LAN connection before entering OS!
AI NET2 remotely detects cable connection the second you turn on the system,
and any faulty connections are reported back up to 100 meters at 1 meter
accuracy.

Asus M2N68 Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio output channels	7.1 channels
Motherboard form factor	ATX
LAN controller	Realtek RTL8211CL
Networking features	NVIDIA nForce Gigabit MAC
BIOS memory size	64 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Depth	236 mm
Width	305 mm
