2-16 Chapter 2: BIOS setup
2.3.4 Storage Conguration
The items in this menu allow you to set or change the congurations for the IDE or
Serial-ATA devices installed in the system. Select an item then press <Enter> if you
wish to congure the item.
Storage Conguration
Onboard IDE Controller [Enabled]
Serial-ATA Devices [Enabled]
SATA Mode select [SATA Mode]
Onboard IDE Controller [Enabled]
Allows you to enable or disable the onboard IDE controller.
Conguration options: [Disabled] [Enabled]
Serial-ATA Devices [Enabled]
Allows you to enable or disable the serial-ATA devices.
Conguration options: [Disabled] [Enabled]
SATA Mode select [SATA Mode]
Conguration options: [SATA Mode] [RAID Mode] [AHCI Mode]
2.3.5 Primary IDE Master/Slave
While entering Setup, the BIOS automatically detects the presence of IDE devices.
There is a separate sub-menu for each IDE device. Select a device item then
press <Enter> to display the IDE device information.
Primary IDE Master
Device : Hard Disk
Vendor : ST320413A
Size : 20.0GB
LBA Mode : Supported
Block Mode : 16 Sectors
PIO Mode : Supported
Async DMA : MultiWord DMA-2
Ultra DMA : Ultra DMA-5
SMART Monitoring: Supported
Type [Auto]
LBA/Large Mode [Auto]
Block(Multi-Sector Transfer) M [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
SMART Monitoring [Auto]
32Bit Data Transfer [Enabled]
Exit
Disabled: disables
the integrated IDE
Controller.
Enabled: enable
the integrated IDE
Controller.
Select the type
of device connected
to the system.

Asus M2N68 Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio output channels	7.1 channels
Motherboard form factor	ATX
LAN controller	Realtek RTL8211CL
Networking features	NVIDIA nForce Gigabit MAC
BIOS memory size	64 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Depth	236 mm
Width	305 mm
