1.7.2 Memory congurations
You may install 512MB, 1GB, 2GB, and 4GB unbuffered ECC and non-ECC DDR3 DIMMs
into the DIMM sockets.
• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel conguration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows
®
OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
- Install a maximum of 3GB system memory if you are using a 32-bit WindowsInstall a maximum of 3GB system memory if you are using a 32-bit Windows
®
OS.
- Use a 64-bit WindowsWindows
®
OS if you want to install 4GB or more memory on the
motherboard.
• This motherboard does not support DIMMs made up of 256 megabits (Mb) chips or less.
M4A78LT-M LX Motherboard Qualied Vendors Lists (QVL)
DDR3-1866(O.C.) MHz capability
Vendor Part No. Size SS/DS Brand Chip NO.
Timing
DIMM
(BIOS)
Voltage
DIMM Support
A* B*
Apacer 78.0AGCD.CDZ(XMP) 2048MB(Kit of 2) SS N/A Heat-Sink Package •
Corsair CM3X2G1800C8D 2048MB DS N/A Heat-Sink Package • •
Transcend TX1800KLU-2GK 1024MB SS N/A Heat-Sink Package • •
Vendor Part No. Size
SS/
DS
Brand Chip NO.
Timing DIMM
(BIOS)
Voltage
DIMM
Support
A* B*
A-Data AD31600X002GMU 4096MB(Kit of 2) DS N/A Heat-Sink Package 7-7-7-20 1.75-1.85V • •
Corsair CM3X1G1600C9DHX 2048MB(Kit of 2) SS N/A Heat-Sink Package 9-9-9-24 1.8V • •
Corsair CM3X2G1600C9DHX 2048MB DS N/A Heat-Sink Package • •
Corsair TR3X6G1600C8 G(XMP) 6144MB(Kit of 3 ) DS N/A Heat-Sink Package • •
Corsair TR3X6G1600C8D G(XMP) 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 8-8-8-24 1.65V • •
Corsair TR3X6G1600C9 G(XMP) 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 9-9-9-24 1.65V • •
Corsair TR3X6G1600C8D G(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 1.65V • •
Crucial BL12864BA1608.8SFB(XMP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 8-8-8-24 1.8V •
Crucial BL12864BE2009.8SFB3(EPP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 9-9-9-28 2.0V • •
Crucial BL25664BN1608.16FF(XMP) 6144MB(Kit of 3 ) DS N/A Heat-Sink Package • •
Crucial BL25664TB1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 •
Crucial BL25664TG1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 • •
Crucial BL25664TR1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 • •
DDR3-1600(O.C.) MHz capability
continued on the next page
Chapter 1: Product introduction1-12

Asus M4A78LT-M LX Specifications

General

ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	4
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	DOS Windows XP Windows XP 64bit Windows Vista 32bit Wnindows Vista 64bit Windows 7 Windows 7 64bit
Graphics card	Radeon 3000
Maximum graphics card memory	1024 MB
Parallel processing technology support	Hybrid CrossFireX
RAID levels	0, 1, 10, JBOD
Controller interface type	SATA 3.0 Gb/s
Cables included	SATA
Bundled software	ASUS PC Probe II ASUS Update
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	203 mm
Width	244 mm
