2-8 Chapter 2: BIOS information
LBA/Large Mode [Auto]
Enables or disables the LBA mode. Setting this item to [Auto] enables the LBA mode if the
device supports this mode, and if the device was not previously formatted with LBA mode
disabled. Conguration options: [Disabled] [Auto]
Block (Multi-Sector Transfer) M [Auto]
Enables or disables data multi-sectors transfers. When this item is set to [Auto], the data
transfer from and to the device occurs multiple sectors at a time if the device supports multi-
sector transfer feature. When this item is set to [Disabled], the data transfer from and to the
device occurs one sector at a time. Conguration options: [Disabled] [Auto]
PIO Mode [Auto]
Selects the PIO mode. Conguration options: [Auto] [0] [1] [2] [3] [4]
DMA Mode [Auto]
Selects the DMA mode. Conguration options: [Auto]
SMART Monitoring [Auto]
Sets the Smart Monitoring, Analysis, and Reporting Technology.
Conguration options: [Auto] [Disabled] [Enabled]
32Bit Data Transfer [Enabled]
Enables or disables 32-bit data transfer. Conguration options: [Disabled] [Enabled]
2.3.4 SATA Conguration
The SATA Conguration menu allows you to congure your storage devices. Select an item
then press <Enter> to display the submenu.
OnChip SATA Channel [Enabled]
Enables or disables the onboard channel SATA port. Conguration options: [Disabled]
[Enabled]
SATA Port1 – Port4 [IDE]
Congures SATA 1/2/3/4. Conguration options: [IDE] [RAID] [AHCI]
SATA Port5 – Port6 [IDE]
Congures SATA 5/6. Conguration options: [IDE] [RAID] [AHCI]
• When SATA 1/2/3/4 are congured as [IDE], SATA 5/6 can only be congured as [IDE].
• When SATA 1/2/3/4/5/6 are congured as [AHCI], only SATA 1/2/3/4 can be detected
under OS. Ensure to install the AHCI driver, so that you can use SATA 1/2/3/4/5/6 in
AHCI mode under OS.
• When SATA 1/2/3/4 are congured as [AHCI] and SATA 5/6 are congured as [IDE], you
can access the devices on SATA 5/6 before entering OS.
