ASUS MAXIMUS IX FORMULA

2-9

Chapter 2

2.1.7 Front I/O connector

To install ASUS Q-Connector

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector To install system speaker connector

USB 3.0

To install USB 3.0 connector

USB 3.1

To install USB 3.1 connector

Thisconnectorwillonlytinone

orientation. Push the connector until it

clicks into place.
