5-12 Chapter 5: Software support
5.3.3 Audio congurations
The Realtek
®
ALC882 audio CODEC provides 8-channel audio capability
to deliver the ultimate audio experience on your computer. The software
provides Jack-Sensing function, S/PDIF Out support, and interrupt
capability. The ALC882 also includes the Realtek
®
proprietary UAJ
®
(Universal Audio Jack) technology for all audio ports, eliminating cable
connection errors and giving users plug and play convenience.
Follow the installation wizard to install the Realtek
®
Audio Driver from the
support CD that came with the motherboard package.
If the Realtek audio software is correctly installed, you will nd the Realtek
HD Audio Manager icon on the taskbar.
From the taskbar, double-click on the
SoundEffect icon to display the Realtek
HD Audio Manager.
Realtek HD Audio Manager
Control
settings
window
Conguration
options
Information
button
Realtek HD Audio Manager
Tool button
Exit button
Minimize
button
