Asus Motherboard P5LD2 User Manual

A-2 Appendix: CPU features
A.2.2 Using the EIST
To use the EIST feature:
1. Turn on the computer, then enter the BIOS Setup.
2. Go to the Advanced Menu, highlight CPU Conguration,
then press <Enter>.
3. Set the Intel(R) SpeedStep Technology item to [Automatic],
then press <Enter>. See page 4-26 for details.
4. Press <F10> to save your changes and exit the BIOS setup.
5. After the computer restarts, right click on a blank space on the desktop,
then select Properties from the pop-up menu.
6. When the Display Properties
window appears, click the Screen
Saver tab.
7. Click the Power button on the
Monitor power section to open
the Power Options Properties
window.
8. On the Power schemes section, click
, then select any option
except Home/Ofce Desktop or
Always On.
9. Click Apply, then click OK.
10. Close the Display Properties
window.
After you adjust the power
scheme, the CPU internal
frequency slightly decreases
when the CPU loading is low.
The screen displays and procedures may vary depending on the
operating system.

Asus Motherboard P5LD2 Specifications

General

Chipset	Intel 945P
Socket	LGA 775
Front Side Bus	1066/800/533 MHz
Memory Type	DDR2
Memory Standard	DDR2 667/533/400
Maximum Memory	4GB
PCI Express x16	1
PCI Express x1	2
PCI Slots	3
SATA	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC882
LAN Speed	10/100/1000Mbps
PS/2	2
Form Factor	ATX
Supported CPU	Intel Pentium 4 / Pentium D / Celeron D
Memory Slots	4
IDE	1 x ATA100
Audio Channels	8
USB 2.0	8
