Asus Motherboard P5LD2 User Manual

2-12 Chapter 2: Hardware information
5. Rotate each fastener clockwise
to ensure correct orientation
when reinstalling.
The narrow end of the
groove should point
outward after resetting.
(The photo shows the
groove shaded for
emphasis.)
Narrow end of the groove
Refer to the documentation in the boxed or stand-alone CPU fan package
for detailed information on CPU fan installation.

Asus Motherboard P5LD2 Specifications

General

Chipset	Intel 945P
Socket	LGA 775
Front Side Bus	1066/800/533 MHz
Memory Type	DDR2
Memory Standard	DDR2 667/533/400
Maximum Memory	4GB
PCI Express x16	1
PCI Express x1	2
PCI Slots	3
SATA	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC882
LAN Speed	10/100/1000Mbps
PS/2	2
Form Factor	ATX
Supported CPU	Intel Pentium 4 / Pentium D / Celeron D
Memory Slots	4
IDE	1 x ATA100
Audio Channels	8
USB 2.0	8
