Asus P4P800 SE User Manual

ASUS P4P800 SE motherboard 2-5
Internal Connectors Page
1. Floppy disk connector (34-1 pin FLOPPY) 2-25
2. Primary IDE connector (40-1 pin PRI_IDE1) 2-25
3. Secondary IDE connector (40-1 pin SEC_IDE1) 2-25
4. Serial ATA connectors (7-pin SATA1, SATA2) 2-26
5. CPU fan connector (3-pin CPU_FAN) 2-28
6. Power fan connector (3-pin PWR_FAN) 2-28
7. Chassis fan connector (3-pin CHA_FAN) 2-28
8. Serial Port 2 connector (10-1 pin COM2) 2-28
9. ATX power connector (20-pin ATXPWR) 2-29
10. ATX 12V power connector (4-pin ATX12V) 2-29
11. USB headers (10-1 pin USB_56, USB_78) 2-30
12. CD connector (4-pin CD) 2-31
13. AUX connector (4-pin AUX) 2-31
14. MODEM connector (4-pin MODEM) 2-31
15. Front panel audio connector (10-1 pin FP_AUDIO) 2-31
16. GAME/MIDI connector (16-1 pin GAME) 2-32
17. Chassis Intrusion connector (4-1 pin CHASSIS) 2-32
18. System panel connector (20-pin PANEL) 2-33
- System Power LED Lead (Green 3-1 pin PLED)
- System Warning Speaker Lead (Orange 4-pin SPKR)
- Reset Switch (Blue 2-pin RESET)
- ATX Power Switch (Yellow 2-pin PWRBTN)
- System Management Interrupt Lead (Light Blue 2-pin SMI)
- Hard Disk Activity LED (Red 2-pin IDE_LED)

Asus P4P800 SE Specifications

General

I/O ports	1 x Parallel 1 x Serial 1 x S/PDIF Output 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x Audio I/O 1 x RJ45 4 x USB 2.0/1.1
Controller interface type	UltraDMA 100/66/33, Serial ATA, RAID 0, 1
Motherboard form factor	ATX
Networking features	Marvell 88E8001 Gigabit Lan Controller 10/100/1000 BASE-T
Bundled software	Drivers ASUS PC Probe ASUS AI Booster Trend Micro PC-cillin anti-virus software (OEM version) ASUS LiveUpdate Utility
Processor socket	Socket 478
Processor manufacturer	Intel
