Asus P4P800 User Manual

ASUS P4P800 motherboard user guide 5-11
Using ASUS PC Probe
Monitoring
Monitor Summary
Shows a summary of the items
being monitored.
Temperature Monitor
Shows the PC temperature (for
supported processors only).
Temperature Warning
threshold adjustment
(Move the slider up to increase the
threshold level or down to decrease
the threshold level)
Fan Monitor
Shows the PC fan rotation.
Voltage Monitor
Shows the PC voltages.
Fan Warning
threshold adjustment
(Move the slider up to increase the
threshold level or down to decrease
the threshold level)

Asus P4P800 Specifications

General

Chipset	Intel 865PE
CPU Support	Intel Pentium 4, Celeron
Socket	Socket 478
Front Side Bus	800/533/400 MHz
Memory Type	DDR SDRAM
Memory Slots	4 x DIMM
Max Memory	4 GB
AGP Slot	1 x AGP 8X
Expansion Slots	5 x PCI
IDE Ports	2 x ATA100
SATA Ports	2 x SATA 1.5Gb/s
Audio Chipset	ADI AD1985
LAN Chipset	3Com 3C940
LAN Speed	10/100/1000 Mbps
Form Factor	ATX
USB Ports	8 x USB 2.0
Audio Channels	6
