1-24 Kapitel 1: Produkteinführung
1.8.3 Interruptzuweisungen
Standard-Interruptzuweisungen
IRQ Priorität Standardfunktion
0 1 System-Zeitgeber
1 2 Tastatur-Controller
2 — An IRQ#9 weiterleiten
3 10 Kommunikationsanschluss (COM1)
4 11 IRQ-Halter für PCI-Steuerung*
5 12 Standarddiskettenlaufwerks-Controller
6 13 Druckeranschluss (LPT1)
7 3 System-CMOS/Echtzeituhr
8 4 IRQ-Halter für PCI-Steuerung*
9 5 IRQ-Halter für PCI-Steuerung*
10 6 IRQ-Halter für PCI-Steuerung*
11 7 PS/2-kompatibler Mausanschluss
12 8 Numerischer Datenprozessor
13 9 Primärer IDE-Kanal
* Diese IRQs sind normalerweise für PCI-Geräte verfügbar.
IRQ-Zuweisungen für dieses Motherboard
A B C D E F G H
PCI1 — — — gemeins. — — — —
PCI2 gemeins. — — — — — — —
PCIEX16_1 gemeins. — — — — — — —
PCIEX1_1 gemeins. — — — — — — —
PCIE WiFi — — gemeins. — — — — —
Onboard USB-Controller 1 — — — — — — — gemeins.
Onboard USB-Controller 2 — — — gemeins. — — — —
Onboard USB-Controller 3 — — gemeins. — — — — —
Onboard USB-Controller 4 gemeins. — — — — — — —
Onboard USB 2.0-Controller — — — — — — — gemeins.
Onboard HD Audio gemeins. — — — — — — —
Onboard LAN — benutzt — — — — — —

Asus P5B-MX WIFI-AP Specifications

General

ECC	No
Non-ECC	Yes
Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Maximum number of SMP processors	1
Number of SATA connectors	4
Special features	ASUS WiFi-AP Solo ASUS CrashFree BIOS 2 ASUS EZ Flash ASUS Q-fan ASUS MyLogo 2
Manageability features	WfM 2.0, DMI, WOL by PME, WOR by PME, PXE
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraDMA 100/66/33
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC883
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS PC Probe II ASUS Update Anti Virus (OEM)
Graphics card	GMA 3000
Maximum graphics card memory	256 MB
Networking features	Gigabit Ethernet, WLAN
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	203 mm
Width	245 mm
