2-24 Chapter 2: BIOS setup
2.4.5 Onboard Devices Conguration
HD Audio Controller [Enabled]
Onboard 1394 Controller [Enabled]
Onboard PCIE GbE LAN [Enabled]
LAN Option ROM [Disabled]
JMicron SATA/PATA Controller [Enabled]
JMicron Controller Mode [BASIC]
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378]
Parallel Port Mode [ECP]
ECP Mode DMA Channel [DMA3]
Parallel Port IRQ [IRQ7]
HD Audio Controller [Enabled]
Allows you to enable or disable the High Denition Audio controller.
Conguration options: [Disabled] [Enabled]
Front Panel Support Type [HD Audio]
Allows you to set the Front Panel Support Type.
Conguration options: [AC97] [HD Audio]
Onboard 1394 Controller [Enabled]
Allows you to enable or disable the onboard 1394 controller.
Conguration options: [Disabled] [Enabled]
Onboard PCIE Gb LAN [Enabled]
Allows you to enable or disable the onboard PCIE Gigabit LAN controller.
Conguration options: [Disabled] [Enabled]
LAN Option ROM [Disabled]
Allows you to enable or disable the boot ROM in the onboard LAN controller.
This item appears only when the Onboard LAN item is set to Enabled.
Conguration options: [Disabled] [Enabled]
JMicron SATA/PATA Controller [Enabled]
Allows you to enable or disable the JMicron SATA/PATA controller.
Conguration options: [Disabled] [Enabled]
JMicron Controller Mode [BASIC]
Allows you to set the JMicron Controller Mode.
Conguration options: [RAID] [BASIC] [AHCI]
Must load the JMB363 driver when create RAID sets, even if all the drivers of
the RAID sets are used as data drivers.

Asus P5B-VM Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Maximum number of SMP processors	1
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	5
Special features	- ASUS AI Gear - ASUS AI Nap - ASUS Advanced Q-Fan - ASUS Q-Connector - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS C.P.R. - ASUS MyLogo 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, RPL
Controller interface type	JMicron JMB363 PATA & SATA
PS/2 ports quantity	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows
Bundled software	ASUS PC Probe II ASUS Update Anti-Virus
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit
RAID levels	0, 1, JBOD
Parallel processing technology support	Not supported

Weight and Dimensions

Width	245 mm
