Asus P5G41T-M LE User Manual

ASUS P5G41T-M LE 1-17
1.9 Jumpers
1. Clear RTC RAM (3-pin CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system passwords.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
• If the steps above do not help, remove the onboard battery and move the jumper again
to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.
• You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature. Shut
down and reboot the system, then the BIOS automatically resets parameter settings to
default values.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5-10 seconds, then move the cap back to pins 1-2.
3. Plug the power cord and turn ON the computer.
4. Hold down the
<Del> key during the boot process and enter BIOS setup to re-enter
data.

Asus P5G41T-M LE Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Maximum Memory	8GB
Storage Interfaces	4 x SATA 3Gb/s
LAN	10/100/1000Mbps
Audio Chipset	Realtek ALC887
Video Outputs	1 x VGA
PS/2 Ports	1 x PS/2 Keyboard, 1 x PS/2 Mouse
Audio Ports	3 x Audio Jacks
Memory Slots	2 x DIMM
Memory Standard	DDR3 1333/1066/800 MHz
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0 (4 at back panel, 4 at mid-board)
Audio	6-channel HD Audio
LAN Chipset	Realtek RTL8111E
Power Connector	24-pin ATX, 4-pin ATX 12V
