Asus P5G41T-M LE User Manual

ASUS P5G41T-M LE 2-5
2.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Main For changing the basic system conguration.
Advanced For changing the advanced system settings.
Power For changing the advanced power management (APM)
conguration.
Boot For changing the system boot conguration.
Tools For conguring options for special functions.
Exit For selecting the exit options and loading default settings.
To select an item on the menu bar, press the right or left arrow key on the keyboard until the
desired item is highlighted.
2.2.1 BIOS menu screen
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
System Time [00:31:48]
System Date [Mon 01/07/2002]
Primary IDE Master :[Not Detected]
Primary IDE Slave :[Not Detected]
SATA 1 :[Not Detected]
SATA 2 :[Not Detected]
SATA 3 :[Not Detected]
SATA 4 :[Not Detected]
Storage Conguration
System Information
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a eld.
Use [+] or [-] to
congure system Time.
Navigation keys
General help
Menu bar
Submenu items
Conguration eldsMenu items
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit

Asus P5G41T-M LE Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Maximum Memory	8GB
Storage Interfaces	4 x SATA 3Gb/s
LAN	10/100/1000Mbps
Audio Chipset	Realtek ALC887
Video Outputs	1 x VGA
PS/2 Ports	1 x PS/2 Keyboard, 1 x PS/2 Mouse
Audio Ports	3 x Audio Jacks
Memory Slots	2 x DIMM
Memory Standard	DDR3 1333/1066/800 MHz
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0 (4 at back panel, 4 at mid-board)
Audio	6-channel HD Audio
LAN Chipset	Realtek RTL8111E
Power Connector	24-pin ATX, 4-pin ATX 12V
