Asus P5G41T-M LE User Manual

ASUS P5G41T-M LE 2-13
2.4.4 Onboard Devices Conguration
Onboard Gigabit LAN [Enabled]
Allows you to enable or disable the onboard Gigabit LAN controller.
Conguration options: [Enabled] [Disabled]
Onboard LAN Boot ROM [Disabled]
Allows you to enable or disable the boot ROM in the onboard LAN controller. This item
appears only when the Onboard LAN item is set to Enabled.
Conguration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses. Conguration options: [Disabled] [378]
[278] [3BC]
Parallel Port Mode [ECP]
Allows you to select the Parallel Port mode.
Conguration options: [Normal] [Bi-Directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item allows you to set
the Parallel Port ECP DMA. Conguration options: [DMA0] [DMA1] [DMA3]
EPP Version [1.9]
Appears only when the Parallel Port Mode is set to [EPP].
Conguration options: [1.9] [1.7]
Parallel Port IRQ [IRQ7]
Allows you to select parallel port IRQ. Conguration options: [IRQ5] [IRQ7]
GTT Graphics Memory Size [No VT mode, 2MB]
This item is not user- congurable.
DVMT Memory [256MB]
Allows you to select the DVMT memory.
Conguration options: [128MB] [256MB] [Maximum DVMT]
Protect Audio Video Path Mode [Lite]
Allows you to select the Protected Audio-Video Path (PAVP) mode.
Conguration options: [Disabled] [Lite] [Paranoid]
South Bridge Conguration
Audio Controller [Enabled]
Allows you to set the audio controller. Conguration options: [Enabled] [Disabled]
Front Panel Type [HD Audio]
Allows you to select the front panel support type. If High Denition Audio Front Panel
used, set this item to [HD Audio] mode. Conguration options: [AC97] [HD Audio]

Asus P5G41T-M LE Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Maximum Memory	8GB
Storage Interfaces	4 x SATA 3Gb/s
LAN	10/100/1000Mbps
Audio Chipset	Realtek ALC887
Video Outputs	1 x VGA
PS/2 Ports	1 x PS/2 Keyboard, 1 x PS/2 Mouse
Audio Ports	3 x Audio Jacks
Memory Slots	2 x DIMM
Memory Standard	DDR3 1333/1066/800 MHz
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0 (4 at back panel, 4 at mid-board)
Audio	6-channel HD Audio
LAN Chipset	Realtek RTL8111E
Power Connector	24-pin ATX, 4-pin ATX 12V

Summary

Product Introduction

Package Contents

Lists all items included in the motherboard package.

Special Features Overview

Highlights key features and technologies of the motherboard.

Installation Precautions

Before You Proceed

General precautions before installing components or changing settings.

Onboard LED Indicator

Explains the function of the motherboard's standby power LED.

Motherboard Overview

Placement Direction and Screw Holes

Guidance on correct motherboard orientation and securing it with screws.

Motherboard Layout and Contents

Visual representation and description of motherboard components and connectors.

CPU Installation and Management

Installing the CPU

Step-by-step instructions for safely installing the CPU into the socket.

CPU Heatsink and Fan Installation

Guide to mounting the CPU heatsink and fan assembly for optimal cooling.

Uninstalling CPU Heatsink and Fan

Procedure for removing the CPU heatsink and fan assembly.

System Memory

Memory Configurations

Details compatible DDR3 memory modules, speeds, and capacity limits.

Installing and Removing DIMMs

Step-by-step processes for installing and removing memory modules.

Expansion Slots

Installing an Expansion Card

Instructions for physically installing expansion cards like PCI and PCIe.

Configuring an Expansion Card

How to configure installed expansion cards via BIOS and drivers.

Jumpers and Connectors

Clear RTC RAM (CLRTC) Jumper

Procedure to clear CMOS settings using the CLRTC jumper.

Rear Panel Connectors

Identification and description of ports on the motherboard's rear panel.

Internal Connectors

Identification and description of internal motherboard connectors.

Software Support

Operating System Installation

Guidance on installing Windows OS versions and necessary drivers.

Support DVD Information

Details the contents and usage of the motherboard support DVD.

BIOS Information

Managing and Updating BIOS

Methods for managing, saving, and updating the motherboard BIOS.

ASUS Update Utility

Instructions for installing and using the ASUS Update utility.

ASUS EZ Flash 2

Guide to updating BIOS via USB or directly from BIOS setup.

ASUS CrashFree BIOS

Procedure for recovering a corrupted BIOS using support media.

BIOS Setup Program

Entering BIOS Setup

Methods to access the BIOS setup utility at startup or after POST.

BIOS Menu Screen Overview

Explanation of the BIOS setup screen layout, menus, and fields.

Menu Bar Functions

Description of the main menu items (Main, Advanced, Power, Boot, Tools, Exit).

Main BIOS Menu

System Time and Date Settings

How to set the system's current time and date.

Device Detection and Configuration

Automatic detection of IDE/SATA devices and storage configuration options.

Advanced BIOS Settings

JumperFree Configuration

Adjusting system frequency and voltage for overclocking.

CPU Frequency Adjustment

Setting the CPU frequency relative to the Front Side Bus.

DRAM Frequency Settings

Configuring the DDR3 memory frequency.

CPU Configuration

Displays CPU-related information and settings.

Chipset Settings

Advanced settings for the North and South bridge chipsets.

Onboard Devices Configuration

Enabling or disabling onboard devices like LAN, audio, and serial ports.

USB Configuration

Settings for USB functions, controllers, and legacy support.

Power Management Settings

Suspend Mode Settings

Selecting the ACPI state for system suspend.

APM Configuration

Options for power-on behavior and AC power loss recovery.

Hardware Monitor

Displays system temperatures, fan speeds, and voltages.

Boot Menu Configuration

Boot Device Priority

Specifying the sequence of bootable devices.

Security Settings

Setting supervisor and user passwords for system security.

BIOS Tools Menu

ASUS EZ Flash 2 Utility

Utility for updating the motherboard BIOS.

Express Gate Configuration

Enabling or disabling the Express Gate instant-on environment.

BIOS Exit Menu

Load Setup Defaults
