ASUS P5LD2ASUS P5LD2

ASUS P5LD2

5-115-11

5-11

3. Click the

RunRun

R u n button to perform a cable test.

5.3.25.3.2

5.3.2

AI NET2AI NET2

AI NET2

The AI NET2 features the Marvell

Virtual Cable Tester™ (VCT). VCT is a

cable diagnostic utility that reports LAN cable faults and shorts using the

Time Domain Reflectometry (TDR) technology. The VCT detects and

reports open and shorted cables, impedance mismatches, pair swaps, pair

polarity problems, and pair skew problems of up to 64 ns at one meter

accuracy.

The VCT feature reduces networking and support costs through a highly

manageable and controlled network system. This utility can be incorporated

in the network systems sofware for ideal field support as well as

development diagnostics.

Using the Virtual Cable Tester™Using the Virtual Cable Tester™

Using the Virtual Cable Tester™

To use the the Marvell

Virtual Cable Tester™ utility:

1. Launch the VCT utility from the Windows

desktop by clicking

Start > All Programs > Marvell > Virtual Cable TesterStart > All Programs > Marvell > Virtual Cable Tester

Start > All Programs > Marvell > Virtual Cable Tester.

2. Click

Virtual Cable Tester Virtual Cable Tester

Virtual Cable Tester from the menu to display the screen below.

• The VCT only runs on systems with Windows

XP or Windows

2000

operating systems.

• The VCT utility only tests Ethernet cables connected to Gigabit LAN

port(s).

• The

RunRun

R u n button on the Virtual Cable Tester™ main window is

disabled if no problem is detected on the LAN cable(s) connected to

the LAN port(s).

• If you want the system to check the status of the LAN cable before

entering the OS, enable the item

Post Check LAN Cable Post Check LAN Cable

Post Check LAN Cable in the

BIOS Setup. See page 4-23 for details.
