5-185-18

5-18

Chapter 5: Software supportChapter 5: Software support

Chapter 5: Software support

5.4.25.4.2

5.4.2

IntelIntel

Intel

®®

RAID configurations RAID configurations

RAID configurations

This motherboard supports RAID 0, RAID 1, RAID 5, RAID 10 (0+1), and

Intel

Matrix Storage configurations for Serial ATA hard disks drives

through the Intel

ICH7R Southbridge chip.

Setting the RAID item in BIOSSetting the RAID item in BIOS

Setting the RAID item in BIOS

You must set the RAID item in the BIOS Setup before you can create a RAID

set(s). To do this:

1. Enter the BIOS Setup during POST.

2. Go to the

Main MenuMain Menu

Main Menu, select

IDE ConfigurationIDE Configuration

IDE Configuration, then press <Enter>.

3. Select the item

Configure SATA AsConfigure SATA As

Configure SATA As, then press <Enter> to display

the configuration options.

4. Select

RAID RAID

RAID from the

Configure SATA As Configure SATA As

Configure SATA As item options, then

press <Enter>.

5. Select the item

Onboard Serial-ATA BOOTROMOnboard Serial-ATA BOOTROM

Onboard Serial-ATA BOOTROM, press <Enter>,

then select

EnabledEnabled

Enabled from the options.

6. Save your changes, then exit the BIOS Setup.

Refer to the system or the motherboard user guide for details on

entering and navigating through the BIOS Setup.

5.4.15.4.1

5.4.1

Installing Serial ATA hard disksInstalling Serial ATA hard disks

Installing Serial ATA hard disks

The motherboard supports Serial ATA hard disk drives. For optimal

performance, install identical drives of the same model and capacity when

creating a disk array.

To install the SATA hard disks for a RAID configuration:

1. Install the SATA hard disks into the drive bays.

2. Connect the SATA signal cables.

3. Connect a SATA power cable to the power connector on each drive.
