ASUS P5LD2ASUS P5LD2
ASUS P5LD2ASUS P5LD2
ASUS P5LD2
4-174-17
4-174-17
4-17
Onboard IDE Operate Mode [Enhanced Mode]Onboard IDE Operate Mode [Enhanced Mode]
Onboard IDE Operate Mode [Enhanced Mode]Onboard IDE Operate Mode [Enhanced Mode]
Onboard IDE Operate Mode [Enhanced Mode]
Allows selection of the IDE operation mode depending on the installed
operating system (OS). Set to [Enhanced Mode] if you are using native OS
including Windows
®
2000/XP. Configuration options: [Disabled]
[Compatible Mode] [Enhanced Mode]
Enhanced Mode Support On [S-ATA]
Allows you to use native OS on Serial ATA and Parallel ATA ports. It is
recommend that you do not change the default setting for better OS
compatibility. In this setting, you may use legacy OS on the Parallel
ATA ports only if you do not install any Serial ATA device.
The P-ATA+S-ATA and P-ATA options are for advanced users only. If
you set to any of these options and encountered problems, revert to
the default setting
S-ATAS-ATA
S-ATAS-ATA
S-ATA. Configuration options: [S-ATA+P-ATA]
[S-ATA] [P-ATA]
The
Onboard IDE Operate Mode Onboard IDE Operate Mode
Onboard IDE Operate Mode Onboard IDE Operate Mode
Onboard IDE Operate Mode and sub-menu items appear only
when the
Configure SATA As Configure SATA As
Configure SATA As Configure SATA As
Configure SATA As item is set to [Standard IDE].
Onboard Serial-ATA BOOTROM [Enabled]
Enables or disables the onboard Serial ATA boot ROM.
Configuration options: [Disabled] [Enabled]
The
Onboard Serial-ATA BOOTROM Onboard Serial-ATA BOOTROM
Onboard Serial-ATA BOOTROM Onboard Serial-ATA BOOTROM
Onboard Serial-ATA BOOTROM appears only when the
Configure SATA As Configure SATA As
Configure SATA As Configure SATA As
Configure SATA As item is set to [RAID].
If you want to use the Serial ATA hard disk drives as Parallel ATA physical
storage devices, set this item to [Standard IDE].
If you want the Serial ATA hard disk drives to use the Advanced Host
Controller Interface (AHCI), set this item to [AHCI]. For details on AHCI, go
to: www.intel.com/support/chipsets/imst/sb/CS-012304.htm
www.intel.com/support/chipsets/imst/sb/CS-012305.htm
The SATA controller is set to Native mode when this item is set to [RAID]
or [AHCI].

Asus P5LD2 Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Maximum number of SMP processors	1
CPU fan connector	Yes
USB 2.0 connectors	2
Manageability features	WOL (PME) WOR (PME) Chassis Intrusion
Controller interface type	Serial ATA
Controller 2nd interface type	UltraDMA
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
BIOS type	AMI
BIOS memory size	32 Mbit
Audio chip	Realtek ALC882
Audio output channels	7.1 channels
Motherboard form factor	ATX
Bundled software	Drivers ASUS PC Probe II AI Booster AntiVirus ASUS LiveUpdate
Parallel processing technology support	Not supported
RAID levels	1, 5, 10

Weight and Dimensions

Depth	23 mm
Width	30.5 mm
