4.6.3 Hardware Monitor
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU1 Temperature [ 35ºC/ 94ºF]
MB1 Temperature [ 30ºC/ 86ºF]
TR1 Temperature [ N/A ]
CPU Fan1 Speed [ 5357RPM]
Front Fan1 Speed [ N/A ]
Front Fan2 Speed [ N/A ]
Front Fan3 Speed [ N/A ]
Rear Fan1 Speed [ N/A ]
Fan Speed Control [Generic Mode]
VCORE1 [ 1.052 V]
+3.3V [ 3.246 V]
+5V [ 5.196 V]
+12V [12.000 V]
VBAT [ 3.126 V]
+3VSB [ 3.198 V]
+1.5V [ 1.504 V]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU1 Temperature
CPU1/MB1/TR1 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the motherboard
component and CPU temperatures. Select [Ignored] if you do not wish to display
the detected temperatures.
CPU Fan1; Front Fan1–3 Speed [xxxxRPM] or [Ignored] / [N/A]
Rear Fan1 Speed [xxxxRPM] or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fans in rotations per minute (RPM). If the fan is not
connected to the motherboard, the eld shows [N/A].
Fan Speed Control [Generic Mode]
Allows you to congure the ASUS Smart Fan feature that smartly adjusts the fan
speeds for more efcient system operation.
Conguration options: [Full Speed Mode] [High Density Mode] [Generic Mode]
[Whisper Mode]
VCORE1, +3.3V, +5V, +12V, VBAT, +3VSB, +1.5V
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators. Select [Ignored] if you do not want to detect this
item.
