ASUS P8H61-M LX R2.01-8
1.5.3 Motherboard layout
1.5.4 Layout contents
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. CPU and chassis fan connectors
(4-pin CPU_FAN, 3-pin CHA_FAN)
1-23 7. System panel connector (10-1 pin F-PANEL) 1-25
2. ATX power connectors (24-pin EATXPWR,
4-pin ATX12V)
1-22 8. Speaker connector (4-pin SPEAKER) 1-22
3. Intel
®
LGA1155 CPU socket 1-8 9. Clear RTC RAM (3-pin CLRTC) 1-19
4. DDR3 DIMM slots 1-13 10. USB connectors (10-1 pin USB56, USB78) 1-23
5. Intel
®
H61 Serial ATA 3.0Gb/s connectors
(7-pin SATA3G_1/2/3/4)
1-24 11. Digital audio connector (4-1 pin SPDIF_OUT) 1-24
6. Standby power LED (SB_PWR) 1-1 12. Front panel audio connector (10-1 pin AAFP) 1-21
P8H61-M LX R2.0
PCIEX16
PCIEX1_1
PCIEX1_2
PCIEX1_3
F_PANEL
SPEAKER
SPEAKER
CLRTC
USB78USB56
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887
RTL
8111E/
8111F
DIGI
+VRM
8Mb
BIOS
SB_PWR
SPDIF_OUT
24.4cm(9.6in)
LGA1155
Intel
®
H61
DDR3 DIMM_A1 (64bit, 240-pin module)
DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_1
SATA3G_3
SATA3G_2
SATA3G_4
AUDIO
KBMS
LAN1_USB12
USB34
18.3cm(7.2in)
VGA
LPT
COM
321 41
6
2
789101112
5

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-M LX PLUS R2.0 and is the answer not in the manual?

Asus P8H61-M LX PLUS R2.0 Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Maximum number of SMP processors1
Number of SATA II connectors4
Number of Parallel ATA connectors-
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component forPC
Power source typeATX
Motherboard chipsetIntel® H61
Audio output channels7.1 channels
Motherboard form factormicro ATX
Supported storage drive interfacesSATA II
Maximum resolution2048 x 1536 pixels
PCI Express x1 slots3
PCI Express slots version2.0, 3.0
Networking featuresGigabit Ethernet
BIOS typeAMI
ACPI version2.0a
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth183 mm
Width244 mm
