ASUS P8Z77-V PREMIUM
1-1
Chapter 1
Product introduction
1
1.1 Special features
1.1.1 Product highlights
LGA1155 socket for Intel® 2nd/3rd Generation Core™ i7 / Core™ i5 / Core™
i3, Pentium®, and Celeron® Processors
This motherboard supports Intel 2nd/3rd generation Core™ i7/i5/i3, Pentium, and Celeron
processors in the LGA1155 package. It provides great graphics and system performance with
its GPU, dual-channel DDR3 memory slots, and PCI Express 2.0/3.0 expansion slots.
Intel
®
Z77 Express Chipset
Intel
®
Z77 Express Chipset is a single-chipset that supports the 1155 socket Intel
®
2nd/3rd
generation Core™ i7/i5/ i3, Pentium
®
, and Celeron
®
processors. It utilizes the serial point-to-
point links, which increases bandwidth and enhances the system’s performance. It natively
supports four USB 3.0 ports for up to ten times faster transfer rate than USB 2.0, and enables
the iGPU function for Intel
®
integrated graphics performance.
PCI Express
®
3.0
PCI Express
®
3.0 (PCIe 3.0) is the PCI Express bus standard that provides twice the
performance and speed of PCIe 2.0. It provides an optimal graphics performance,
unprecedented data speed, and seamless transition with its complete backward compatibility
to PCIe 1.0/2.0 devices.
* Intel
®
3rd generation Core™ processors support PCIe 3.0.
Dual-Channel DDR3 2800(O.C.) / 2600(O.C.) / 2400(O.C.) / 2200(O.C.) / 2133(O.
C.) / 1866(O.C.) / 1600 / 1333 / 1066 MHz Support
The motherboard supports the dual-channel DDR3 memory that features data transfer rates
of DDR3 2800(O.C.) / 2600(O.C.) / 2400(O.C.) / 2200(O.C.) / 2133(O.C.) / 1866(O.C.) / 1600
/ 1333 / 1066 MHz to boost the system’s performance, and to meet the higher bandwidth
requirements of 3D graphics, multimedia, and Internet applications.
* Due to Intel
®
2nd generation processor’s behavior, DDR3 2200 (and higher), and DDR3 2000/1800 MHz memory
modules run at default rates of DDR3 2133/1866/1600 MHz.
4-WAY SLI and 3-WAY SLI CrossFireX™ Support
This motherboard features a unique PCIe 3.0 bridge chip to support 4-Way SL/CrossFireX
graphics cards for an unrivaled gaming performance. With the Intel Z77 platform to optimize
the PCIe allocation of multiple GPUs, it supports up to four graphic cards in both SLI or
CrossFireX conguration.

Asus P8Z77-V PREMIUM Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400, 2600, 2800 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	2
Number of SATA II connectors	3
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
I/O ports	1 x Thunderbolt
Controller interface type	Intel Z77
Controller 2nd interface type	Marvell PCIe 9230, ASMedia PCIe
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC898
Component for	PC
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	4-Way SLI, Quad-GPU CrossFireX
Cables included	SATA
LAN controller	Intel® 82579V
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
