Chapter 1: Product introduction
Chapter 1
P8Z77-V PREMIUM Motherboard Qualied Vendors Lists (QVL)
DDR3 2800(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket support
(Optional)
1 2 4
G.skill F3-2800CL11Q-
16GBZHD
16GB
(4x4GB)
DS - - 11-13-
13-35
1.65 • • •
* The 2800MHz memory modules above are supported on Intel
®
3rd generation processors by this motherboard;
however, the actual frequency support varied depending on the O.C. margin of the installed CPU.
** Due to Intel 2nd generation processors' behavior, DDR3 2200 and above/2000/1800 MHz memory module runs ay
DDR3 2133/1866/1600 MHz frequency as default.
DDR3 2666(O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support
(Optional)
1 2 4
G.skill F3-2666CL10Q-16GBZHD 16GB(4x4GB) DS - - 10-12-
12-31
1.65 • •
•
* The 2666MHz memory modules above are supported on Intel
®
3rd generation processors by this motherboard;
however, the actual frequency support varied depending on the O.C. margin of the installed CPU.
** Due to Intel 2nd generation processors' behavior, DDR3 2200 and above/2000/1800 MHz memory module runs ay
DDR3 2133/1866/1600 MHz frequency as default.
DDR3 2600(O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support
(Optional)
1 2 4
G.skill F3-20800CL10-16GBZMD(XMP) 16GB(4x4GB) DS - - 10-12-
12-28
1.65 • • •
G.skill F3-2600CL11Q-32GBZHD 32GB(4x8GB) DS 11-13-
13-35
1.65 • • •
* The 2600MHz memory modules above are supported on Intel
®
3rd generation processors by this motherboard;
however, the actual frequency support varied depending on the O.C. margin of the installed CPU.
** Due to Intel 2nd generation processors' behavior, DDR3 2200 and above/2000/1800 MHz memory module runs ay
DDR3 2133/1866/1600 MHz frequency as default.
DDR3 2500(O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support
(Optional)
1 2 4
G.Skill F3-20000CL10Q-
16GBZHD(XMP)
16GB (4x4GB) DS - - 10-11-
11-31
1.65
• • •
* The 2500MHz memory modules above are supported on Intel
®
3rd generation processors by this motherboard;
however, the actual frequency support varied depending on the O.C. margin of the installed CPU.
** Due to Intel 2nd generation processors' behavior, DDR3 2200 and above/2000/1800 MHz memory module runs ay
DDR3 2133/1866/1600 MHz frequency as default.

Asus P8Z77-V PREMIUM Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400, 2600, 2800 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	2
Number of SATA II connectors	3
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
I/O ports	1 x Thunderbolt
Controller interface type	Intel Z77
Controller 2nd interface type	Marvell PCIe 9230, ASMedia PCIe
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC898
Component for	PC
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	4-Way SLI, Quad-GPU CrossFireX
Cables included	SATA
LAN controller	Intel® 82579V
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
