28
E
SETUP menu
Function
Command Direction
Parameter Reply Control/Response contents
*
LANGUAGE LANG WR 14 14
ENGLISH
º
1 1
DEUTSCH
2 2
FRANÇAIS
3 3
ITALIANO
4 4
ESPAÑOL
5 5
РУССКИЙ
6 6
INPUT SELECT HDMI1 HDSL WR 0-1 0-1 0: PC HDMI, 1: AV HDMI
º
HDMI2 H2SL WR 0-1 0-1 0: PC HDMI, 1: AV HDMI
HDMI DUAL HDDU WR 0-1 0-1 0: OFF, 1: ON
AUDIO SELECT HDMI1 [PC] ASHP WR 0-1 0-1 0: HDMI, 1: STEREO MINI
º
HDMI1 [AV] ASHA WR 0-1 0-1 0: HDMI, 1: STEREO MINI
HDMI2 [PC] AH2P WR 0-1 0-1 0: HDMI, 1: STEREO MINI
HDMI2 [AV] AH2A WR 0-1 0-1 0: HDMI, 1: STEREO MINI
DisplayPort ASDI WR 1-2 1-2 1: DisplayPort, 2: STEREO MINI
AUDIO INPUT LEVEL AIVP WR 0-1 0-1 0: 1.0Vrms, 1: 0.5Vrms
º
BAUD RATE BAUD WR 0-2 0-2 0: 9600bps, 1: 19200bps, 2: 38400bps
º
DisplayPort STREAM DPST WR 0-1 0-1 0: SST, 1: MST
-
MONITOR menu
Function
Command Direction
Parameter Reply Control/Response contents
*
MONITOR STDR WR 0-1 0-1
0: LANDSCAPE, 1: PORTRAIT
º
STANDBY MODE STBM WR 0-1 0-1
0: STANDARD, 1: LOW POWER
º
OFF IF NO OPERATION ATOF WR 0-1 0-1
0: OFF, 1: ON
º
PBP menu
Function
Command Direction
Parameter Reply
Control/Response contents *
PBP MODE MWIN WR 0,2 0,2 0: OFF, 2: ON
“ERR” when HDMI DUAL is ON.
º
PBP SOURCE MWIP WR 9 9 HDMI1 [AV]
º
10 10 HDMI1 [PC]
12 12 HDMI2 [AV]
13 13 HDMI2 [PC]
14 14 DisplayPort
OTHERS menu
Function Command Direction Parameter Reply Control/Response contents
*
SCREEN
MOTION
PATTERN SCSV WR 0,2,3 0,2,3 0: OFF, 2: PATTERN1, 3: PATTERN2
º
MOTION TIME 1 MTIM WR 0-20 0-20
MOTION TIME 2 MINT WR 5-20 5-20 Per second
POWER MANAGEMENT (PC) PMNG WR 0-1 0-1 0: OFF, 1: ON
º
POWER MANAGEMENT (AV) PMAV WR 0-1 0-1 0: OFF, 1: ON
º
SIZE (PC) WIDE WR 1-3 1-3 1: WIDE, 2: NORMAL, 3: Dot by Dot
º
SIZE (AV) WIDE WR 1, 4-5 1, 4-5 1: WIDE, 4: NORMAL, 5: Dot by Dot
º
4096 DISPLAY POSITION 4KDP WR 0-2 0-2 0: LEFT, 1: CENTER, 2: RIGHT
º
MUTE AUDIO MUTE WR 0-1 0-1 0: OFF, 1: ON
-
INFORMATION
MODEL INF1 R Value
•
SERIAL NO SRNO R Value
Controlling the Monitor with a PC (RS-232C)
