Asus PQ321Q User Manual

8
E
Supplied Components
If any component should be missing, please contact your dealer.
• Liquid Crystal Display Monitor: 1
•
Power cord: 1
•
AC adapter: 1
•
Setup Manual: 1
•
DisplayPort cable: 1
•
RS-232C conversion cable (Φ3.5 mini-jack): 1
•
Pedestal (for stand): 1
•
Strut (for stand): 1
•
Attachment plate (for stand): 1 (preinstalled on monitor)
•
Countersunk screws (M4 x 6 without washers): 5
•
Screws (M4 x 10 with washers): 4
•
Hex wrench: 1
•
Cable clamp: 2
•
Cable clamp (small): 1
•
Cable clamp (large): 2
• Horizontal sticker (operation buttons): 1
Contents
IMPORTANT INFORMATION .................................................. 3
DEAR ASUS CUSTOMER ......................................................... 4
SAFETY PRECAUTIONS .......................................................... 4
TIPS AND SAFETY INSTRUCTIONS ........................................ 6
MOUNTING PRECAUTIONS ................................................... 7
Supplied Components .......................................................... 8
Part Names ............................................................................. 9
Installing the stand (supplied) ........................................... 10
Installing the stand (supplied) ........................................... 11
Connecting Peripheral Equipment..................................... 12
Connection with a PC or AV equipment ..................................12
Connecting the Power Cord ................................................ 13
Binding Cables ..................................................................... 14
Turning Power On/O ......................................................... 15
Turning on the main power..........................................................15
Turning power on/o .....................................................................15
Basic Operation ................................................................... 16
Menu Items .......................................................................... 18
Displaying the menu screen ........................................................18
Menu item details ............................................................................19
Initialization (Reset)/Functional Restriction Setting
(FUNCTION) .......................................................................... 23
Controlling the Monitor with a PC (RS-232C) .................... 24
PC connection ...................................................................................24
Communication conditions..........................................................24
Communication procedure ..........................................................24
RS-232C command table ...............................................................26
Troubleshooting .................................................................. 30
Specications ...................................................................... 31
Mounting Precautions
(For ASUS dealers and service engineers) ......................... 36

Asus PQ321Q Specifications

General

Brand	Asus
Model	PQ321Q
Category	Monitor
Language	English
