Chapter 1: Knowing your wireless router RT-N10E
Mounting options
Out of the box, the ASUS Wireless Router is designed to sit on a raised at surface
like a le cabinet or book shelf. The unit may also be converted for mounting to a
wall or ceiling.
To mount the ASUS Wireless Router:
1. Look on the underside for the two mounting hooks.
2. Mark two upper holes in a at surface.
3. Tighten two screws until only 1/4'' is showing.
4. Latch the hooks of the ASUS Wireless Router onto the screws.
Note: Re-adjust the screws if you cannot latch the ASUS Wireless Router onto the screws or if
it is too loose.

Asus RT-N10E Specifications

General

Frequency Band	2.4 GHz
Max Data Rate	150 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Wireless Standard	IEEE 802.11b/g/n
Security	64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK
Firewall	SPI Firewall
Storage Temperature	-20°C to 70°C
Antenna	1 external antenna
Storage Humidity	5% to 90% non-condensing
