Asus RT-N10E User Manual

23
Chapter 4: Conguring via the web GUI RT-N10E
3. Click Next and key in the necessary information for your ISP connection type.
Important: Obtain the necessary information about your Internet connection type from your ISP.
Setting up the wireless router in Access Point mode
In the Access Point mode, the wireless router receives the WAN IP address from
the router connected to the WAN port and provides you with wireless radio signals.
The NAT, rewall, and IP sharing services are disabled.
To set up the wireless router in AP mode:
1. From the navigation menu, click Advanced Setting > Administration >
Operation Mode tab.
2. Tick Access Point and click Save.
3. Key in your network name (SSID) and network key. Click Finish when done.

Asus RT-N10E Specifications

General

Frequency Band	2.4 GHz
Max Data Rate	150 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Wireless Standard	IEEE 802.11b/g/n
Security	64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK
Firewall	SPI Firewall
Storage Temperature	-20°C to 70°C
Antenna	1 external antenna
Storage Humidity	5% to 90% non-condensing
