Asus RT-N13 User Manual

10
RT-N13 Chapter 2: Setting up the hardware
Setting up a wireless connection
To set up a wireless connection:
1. Turn on your router and the modem.
 
3. Connect an IEEE 802.11b/g/n compatible WLAN card. Refer to your wirelessRefer to your wireless
adapter user manual for wireless connection procedures. By default, the SSID
of ASUS Wireless Router is “default” (in lower case), encryption is disabled and
open system authentication is used.
WAN
Conguring the wireless router
The ASUS Wireless Router includes a web graphics user interface (web GUI)

computer.
Using the web GUI
If your PC connects to the router using a cable, launch a web browser and the


To select the network:
1. Click Start > Control Panel > Network Connections > Wireless Network
Connection.
2. Select a network from the Choose a wireless network window. Wait for it to
connect.
Note: By default, the SSID of the wireless router is default. Connect to this default SSID.

Asus RT-N13 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Ethernet LAN interface type	Fast Ethernet
Input voltage	100 - 240 V
Frequency range	2.4 - 2.5 GHz
Input frequency	50 / 60 Hz
Dimensions (WxDxH)	- mm
Power requirements	5V DC, 2.5A
Networking features	Fast Ethernet, WLAN, WAN
Filtering description	URL
Output power description	15.5~16.5dBm(g), 15.8~19.5dBm(b), 15.8~19.5dBm(n)
Supported data transfer rates	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300Mbps
WLAN data transfer rates supported	300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA, WPA-AES, WPA-PSK, WPA-TKIP, WPA2, WPA2-PSK
Product color	White
Supported network protocols	PPTP, PPPoE, L2TP
Antenna gain level (max)	15.8 dBi

Weight and Dimensions

Weight	- g
