Asus RT-N13 User Manual

21
           
Icon Description
Client status
Click this icon to display information about the clients or
computers in the network, and allows you to block/unblock
a client.
Setting up WAN using the Quick Internet Setup (QIS)
The Quick Internet Setup (QIS) function automatically detects the Internet
connection type. It guides you in setting up your WAN when encountering special
Internet connection types.
To set up your WAN using QIS:
1. Under Internet status, click GO in the QIS
2. Select your connection type from these types of ISP services: Automatic IP,
PPPoE, PPTP, L2TP, and Static IP.
3. Click Apply all settings to save the settings.

Asus RT-N13 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Ethernet LAN interface type	Fast Ethernet
Input voltage	100 - 240 V
Frequency range	2.4 - 2.5 GHz
Input frequency	50 / 60 Hz
Dimensions (WxDxH)	- mm
Power requirements	5V DC, 2.5A
Networking features	Fast Ethernet, WLAN, WAN
Filtering description	URL
Output power description	15.5~16.5dBm(g), 15.8~19.5dBm(b), 15.8~19.5dBm(n)
Supported data transfer rates	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300Mbps
WLAN data transfer rates supported	300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA, WPA-AES, WPA-PSK, WPA-TKIP, WPA2, WPA2-PSK
Product color	White
Supported network protocols	PPTP, PPPoE, L2TP
Antenna gain level (max)	15.8 dBi

Weight and Dimensions

Weight	- g
